Product specification: Spot welding machine
| Industry basic attributes | WS7-016 | Product custom attributes | |
| Types of machines | Seam Welding Machine | Product Name | Seam Welding Machine |
| Rated capacity | 16KVA | Rated Frequency (Hz) | 50Hz |
| Type | Welding Head | Maximum Short-Circuit Current | 25KA |
| Material |
Iron Stainless Steel Metal Copper Carbon |
Maximum Pressure | 200N |
| Maximum input power | 16KW | Stroke of Upper Electrode | 40/80mm |
| Status | New | Stroke of Lower Electrode | 55mm |
| Voltage | 380V | The Max Welding Length (Deep*Height) | 350mm |
| Origin | China | Dimension Between Arms | 435mm |
| Province | Guangdong | Cooling Water Volume | 2L/min |
| Brand | JinChun | Electrode Size | 14mm |
| Warranty period | 1 Year | Is customization available | Customizable |
| Weight (KG | 400KG | ||
| Current | 39.5KA | ||
| Rated load duration | 50% | ||
| Size specification | 1250*600*1800mm | Logistics attribute | Volume and weight (including logistics packaging) |
| Purpose | Welding Machine | Gross weight (KG) : Customizable | Length (CM) : Customizable |
| Welding form | TIG/AC RW/IF RW | Width (CM) : Customizable | Height (CM) : Customizable |
This high-performance mesh welder features a rectangular welding head designed for processing metal wires and flat bars (iron, stainless steel, aluminum, copper) up to 16mm in diameter. It is specially engineered for producing mesh panels with selectable welding methods based on material type. Custom welding and positioning jigs ensure strong, pull-test passing welds, while adjustable current delivers smooth, scar-free surfaces. With foot pedal operation supporting both single and continuous welding modes, it achieves an output of 20-25 spots per minute. The user-friendly multilingual button and touch control interface allows beginners to learn within 5 minutes. Ideal for welding mesh products including BBQ grids, pet cages, shopping carts, and shelving. The machine offers over 10 years of service life, less than 3% annual failure rate, under 2-hour after-sales response time, 1-year warranty, strict QC inspection, and CE certification.
