Product specification: 2-axis flying shears 1-3mm
| Industry basic attributes | Product custom attributes | ||
| Voltage | 380-440V | Product Name | Straightening Machine with Flying Shear |
| Power (horsepower | 7.3KW | Number of Axes | 2 Axis |
| Feeding speed | 80-130m/min | Suitable Wire Material | Low Carbon Iron Wire |
| Type | Straightener & Cutter | Suitable For Wire Diameter | 1-3mm |
| Purpose | Wire | Length Deviation in Cutting | ±0.5mm |
| Warranty period | 1 Year | Cutting Length Range | Above 80mm |
| Weight (KG | 750KG | Wire Feeding Motor Power | 1.5KW |
| Origin | China | Straightening Servo Motor Power | 3.0KW |
| Province | Guangdong | Cutter Servo Motor Power | 2.8KW |
| Video factory inspection | Provided | Number of Straightening Blocks | 10 pcs |
| Mechanical test report | Provided | Is customization available | Customizable |
| Core component | PLC、Engine、Motor | ||
| Brand | JinChun | ||
| Dimensions (length × width × height) | 2350*750*1550(mm) | Logistics attribute | Volume and weight (including logistics packaging) |
| Core selling point | High-accuracy，Automatic，Easy to Operate | Gross weight (KG) : 800KG | Length (CM) : 240 |
| Product application | Straightener & Cutter | Width (CM) : 80 | Height (CM) : 173 |
This high-speed straightening and cutting machine efficiently processes round or flat bars (iron, stainless steel, aluminum, copper) with diameters of 1–7mm, requiring only quick mold changes for material adaptation. It delivers cutting lengths from 45mm to 8m at speeds of 80–130 meters per minute, with precision up to 0.02mm. The straightened output is burr-free, scratch-resistant, and smooth. Universal molds reduce changeover time, while optional functions include stamping, flattening, and dot punching. Equipped with a multilingual smart control system (buttons + touchscreen), it allows new users to learn within 30 minutes. Ideal for BBQ grids, shopping carts, pet cages, and highway guardrails, the machine offers a service life exceeding 10 years, under 3% annual failure rate, under 2-hour after-sales support, 1-year warranty, QC inspection, and CE certification.
