Product specification: Spot welding machine
| Industry basic attributes | WS6-016 | Product custom attributes | |
| Rated capacity | 16KVA | Product Name | Spot Welding Machine |
| Maximum welding thickness | 32mm | Rated Frequency (Hz) | 50Hz |
| Voltage | 380V | Maximum Short-Circuit Current | 25KA |
| Power (kW | 16KW | Maximum Pressure | 200N |
| Status | New | Stroke of Upper Electrode | 40/80mm |
| Origin | China | Stroke of Lower Electrode | 55mm |
| Province | Guangdong | The Max Welding Length（Deep*Height) | 350mm |
| Brand | JinChun | Dimension Between Arms | 435mm |
| Rated load duration | 50% | Cooling Water Volume | 2L/min |
| Size specification | 1250*600*1800mm | Electrode Size | 14mm |
| Purpose | Welding Machine | Is customization available | Customizable |
| Warranty period | 1 Year | ||
| Weight (KG | 400KG | ||
| Logistics attribute | Volume and weight (including logistics packaging) | ||
| Gross weight (KG) : Customizable | Length (CM) : Customizable | Width (CM) : Customizable | Height (CM) : Customizable |
This circular-head spot welder handles metal wire or flat bar (iron, stainless steel, aluminum, copper) up to 16mm thick, delivering 20–25 welds/minute. It supports material-specific welding methods (e.g., AC for iron, MF for stainless steel) and accepts custom jigs for precise, pull-test-resistant welds. Adjustable current ensures smooth, scar-free surfaces. With foot pedal operation and multilingual touch/button controls, beginners can operate within 5 minutes. Ideal for hardware assembly, it offers 10-year service life, <3% annual failure rate, <2-hour after-sales response，1-year warranty, QC inspection, and CE certification. Suitable for high-volume production of shopping carts, cages, and mesh products.
