Product specification: Spot welding machine
| Industry basic attributes | WS6-016 | Product custom attributes | |
| Rated capacity | 16KVA | Product Name | Spot Welding Machine |
| Maximum welding thickness | 32mm | Rated Frequency (Hz) | 50Hz |
| Voltage | 380V | Maximum Short-Circuit Current | 25KA |
| Power (kW | 16KW | Maximum Pressure | 200N |
| Status | New | Stroke of Upper Electrode | 40/80mm |
| Origin | China | Stroke of Lower Electrode | 55mm |
| Province | Guangdong | The Max Welding Length (Deep*Height) | 350mm |
| Brand | JinChun | Dimension Between Arms | 435mm |
| Rated load duration | 50% | Cooling Water Volume | 2L/min |
| Size specification | 1250*600*1800mm | Electrode Size | 14mm |
| Purpose | Welding Machine | Is customization available | Customizable |
| Warranty period | 1 Year | ||
| Weight (KG | 400KG | ||
| Logistics attribute | Volume and weight (including logistics packaging) | ||
| Gross weight (KG) : Customizable | Length (CM) : Customizable | Width (CM) : Customizable | Height(CM)：Customizable |
This spot welding machine, with a round welding head, can process metal wire or flat steel (iron, stainless steel, aluminum, copper) ≤16mm. Output: 20-25 points/minute. The welding method can be selected based on the material (e.g., AC for iron, medium frequency for stainless steel). The welding and positioning fixtures can be customized according to the product drawing, ensuring strong welds that can pass tensile tests. The current is adjustable, resulting in smooth, scar-free welds. The machine is operated with a foot pedal, allowing beginners to learn in just 5 minutes. It features multi-language button/touchscreen controls. It is suitable for joining hardware parts. The average machine lifespan exceeds 10 years, with an annual failure rate of less than 3%. The average after-sales service response time is less than 2 hours. This machine comes with a one-year warranty, undergoes rigorous quality control (QC) inspections before shipment, and holds CE certification.
