| Industry Basic Attributes | Product Customizable Attributes | ||
| Machine Type | XY-Axis Welding Machine | Product Name | XY-Axis Welding Machine |
| Rated Capacity | 150KVA | Control Screen | Touch Screen |
| Type | Welding Head | The Max Width Welding Size | 800mm |
| Material |
Iron Stainless Steel Metal Copper Carbon |
The Max Lenght Welding Size | 1250mm |
| Maximum Input Power | 150KW | Working Aire Pressure | 0.5~0.7MPa |
| Condition | New | Working Height | 600-800mm |
| Voltage | 380V | Welding Process | Row Welding |
| Place of Origin | China | Pressurization Mode | Pneumatic |
| Province | Guangdong | X-axis Servo Motor Power | 0.75KW,2000R |
| Brand | JinChun | Y-axis Servo Motor Power | 1.5KW,3000R |
| Warranty Period | 1 Year | Is customization available | Customizable |
| Weight (KG) | 800KG | ||
| Electric Current | 38.5KA | ||
| Rated Load Duty Cycle | 50% | ||
| Size Specification | 2800mm*2200mm*1750mm | Logistics Attributes | Volume & Weight (Including Logistics Packaging) |
| Application | Welding Machine | Gross Weight (KG)：Customizable | Length (CM)：Customizable |
| Welding Method | TIG/AC RW/IF RW | Width (CM)：Customizable | Height (CM)：Customizable |
Equipped with 2-10 welding heads and cylinders, excellent for mesh panels. Welds 1-3 panels per minute. Operator places material using a wire shaking feeder while welding occurs simultaneously, reducing skill dependency. Processes wire/flat bar ≤16mm. Selectable welding methods. Custom jigs ensure strong, test-passing welds with smooth surfaces. Operators can learn within 30 minutes. Multilingual controls. Ideal for mesh products (BBQ grids, pet cages, carts, racks). Average service life exceeds 10 years, annual failure rate <3%. Average after-sales response time <2 hours. 1-year warranty. Strict pre-shipment QC. CE certified.
